Λεπτομέρειες:
|
| Ονομαστική τάση: | 48V | Μέγιστο ρεύμα φόρτισης: | 200Α |
|---|---|---|---|
| Ονομαστική χωρητικότητα: | 200 Ah | Μέγεθος μπαταρίας: | 618*480*248 χλστ |
| Ονομαστική Ενέργεια: | 10240Wh | Καθαρό Βάρος: | 85 κιλά |
| Τύπος κυττάρου: | lifepo4 κύτταρο | Πρότυπο ρεύμα φόρτισης: | 100Α |
| Απαλλαγή της κομμένης τάσης: | 56,2 V | Ανώτατο συνεχές ρεύμα απαλλαγής: | 200Α |
| Ρεύμα εκφόρτισης: | 10Α | Τερματικό: | Γρήγορη προσθήκη |
| Επισημαίνω: | 48V 200Ah LiFePO4 wall battery,residential solar storage battery,home battery storage with warranty |
||
| Specification | Details |
|---|---|
| Product Model | KM48V200R |
| Nominal Voltage | 51.2V |
| Nominal Capacity | 200Ah |
| Nominal Energy | 10240Wh |
| Cell Type | LiFePO4 Cell |
| Standard Charging Current | 100A |
| Max Charging Current | 200A |
| Discharging Cut-off Voltage | 56.2V |
| Max Continuous Discharging Current | 200A |
| Discharging Current | 10A |
| BMS Protection | Overcharging/over-discharging, Over-voltage/Over-current, Short Circuit, etc. |
| Case Material | Metal/Custom material |
| Terminal | Fast plug-in |
| Battery Size | 618*480*248mm |
| Net Weight | 85kg |
| Communication | CAN/RS485/RS232/Bluetooth (optional) |
| Shipping Method | Sea/Air/Railway |
| Delivery Time | Quantity within 100pcs: 5-12 days |
A: It works with solar panel arrays, diesel generators and municipal grid power. It supplies stable backup power for home refrigerators, air conditioners, lights, water pumps and essential household loads up to 10kW total power demand. Compatible with most mainstream 48V solar hybrid inverters.
A: Our EVE A-grade LiFePO4 cell design delivers more than 8000 deep discharge cycles, equivalent to over 10 years of daily regular use, much longer than lead-acid or low-grade lithium batteries.
A: Yes. LiFePO4 material features extremely low thermal runaway risk, plus built-in intelligent BMS with full overcharge/short-circuit/temperature protection. It holds CE, UL, RoHS global safety certifications, safe for bedroom, garage and utility room wall mounting.
A: Yes. Multiple units can be parallel connected to expand total storage capacity and power output. Optional CAN/RS485 communication ports realize unified battery monitoring for the whole battery bank.
A: Charging environment: 0℃ ~ 55℃; Discharging environment: -20℃ ~ 60℃. It can stably supply power in cold winter areas and hot tropical regions.
